Cessna 172M -
1974 |
|
Performance - Specifications |
Speed:
Maximum at Sea Level
Cruise, 75% Power at 8000 Feet
Vne (Never Exceed Speed)
Vno (Max. Structural Cruising) |
140 MPH (172) / 144 MPH (Skyhawk)
135 MPH (172) / 138 MPH (Skyhawk)
182 MPH
145 MPH |
Do Not
Use This Information For Flight Planning
|
Cruise: |
|
75% Power at
8000 Feet
38 Gallons Usable Fuel (Model 172)
48 Gallons Usable Fuel (Model 172)
38 Gallons Usable Fuel (Skyhawk)
48 Gallons Usable Fuel (Skyhawk) |
Range: 635 SM / Time: 4.7 HRS / 135 MPH
Range: 795 SM / Time: 5.9 HRS / 135 MPH
Range: 650 SM / Time: 4.7 HRS / 138 MPH
Range: 815 SM / Time: 5.9 HRS / 138 MPH |
Max. Range at 10,000 Feet
38 Gallons Usable Fuel (Model 172)
48 Gallons Usable Fuel (Model 172)
38 Gallons Usable Fuel (Skyhawk)
48 Gallons Usable Fuel (Skyhawk) |
Range: 695 SM / Time: 6.0 HRS / 116 MPH
Range: 870 SM / Time: 7.5 HRS / 116 MPH
Range: 700 SM / Time: 6.0 HRS / 117 MPH
Range: 875 SM / Time 7.5 HRS / 117 MPH |
Rate
of Climb at Sea Level: |
645 FPM |
Service Ceiling: |
13,100 Feet |
Takeoff Performance:
Ground Roll
Total Dist. over 50-FT Obstacle |
865 Feet
1525 Feet |
Landing Performance:
Ground Roll
Total Dist. over 50-FT Obstacle |
520 Feet
1250 Feet |
Stall
Speed (KCAS):
Flaps Up, Power Off
Flaps Down, Power Off |
57 MPH
49 MPH |
Gross Weight: |
2300 Pounds |
Standard Empty Weight:
Model 172
Skyhawk |
1300 Pounds
1345 Pounds |
Maximum Useful Load:
Model 172
Skyhawk |
1000 Pounds
955 Pounds |
Baggage Allowance: |
120 Pounds |
Wing
Loading: |
13.2 Pounds/Sq.Ft. |
Power
Loading: |
15,3 Pounds/HP |
Fuel
Capacity (Total):
Standard Tanks
Long Range Tanks |
42 Gallons / 38 Gallons useable
52 Gallons / 48 Gallons useable |
Oil
Capacity: |
8 Quarts |
Engine: |
Lycoming O-320-E2D / 150 BHP at 2700
RPM |
Propeller: |
75 Inch (diameter) / Fixed Pitch |
Electrical System: |
14-Volt with Alternator; Avionics Master
Switch |
Wingspan: |
35' 10" |
