| Cessna 172RG -
1982 |
|
Performance - Specifications (as of 29
May 1981) |
Speed:
Maximum at Sea Level
Cruise, 75% Power at 9000 Feet
Vne (Never Exceed Speed)
Vno (Max. Structural Cruising) |
145 knots
140 knots
164 KIAS
145 KIAS |
Do Not
Use This Information For Flight Planning
|
|
Cruise: |
|
| 75% Power at
9000 Feet |
Range: 720 NM / Time: 5.3 HRS |
| Max. Range at 10,000 Feet |
Range: 840 NM / Time: 7.7 HRS |
| Rate
of Climb at Sea Level: |
800 FPM |
|
Service Ceiling: |
16,800 Feet |
Takeoff Performance:
Ground Roll
Total Dist. over 50-FT Obstacle |
1060 Feet
1775 Feet |
Landing Performance:
Ground Roll
Total Dist. over 50-FT Obstacle |
625 Feet
1340 Feet |
Stall
Speed (KCAS):
Flaps Up, Power Off
Flaps Down, Power Off |
54 Knots
50 Knots |
Maximum Weight:
Ramp
Takeoff or Landing |
2658 Pounds
2650 Pounds |
Standard Empty Weight:
Cutlass RG
Cutlass RG II |
1591 Pounds
1627 Pounds |
Maximum Useful Load:
Cutlass RG
Cutlass RG II |
1067 Pounds
1031 Pounds |
|
Baggage Allowance: |
200 Pounds |
| Wing
Loading: |
15.2 Pounds/Sq.Ft. |
| Power
Loading: |
14.7 Pounds/HP |
| Fuel
Capacity (Total): |
66 Gallons |
| Oil
Capacity: |
9 Quarts |
|
Engine: |
Avco Lycoming O-360-F1A6 / 180 BHP at 2700
RPM |
|
Propeller: |
76.5 Inch (diameter) / Constant Speed |
|
Electrical System: |
28-volt with Alternator; includes Avionics
Power Switch |
|
Wingspan: |
36 Feet |
